Espagnolette Lock

Espagnolette Lock System

This Espagnolette lock system is designed to lock full height cupboard doors with a three point locking action for added strength. Features include:

 -- The espagnolette lock is made of diecast zinc

-- Operates a 6mm rod rotating to hook onto a hook mounted top and bottom plus an 8mm bolt shoots out the side to lock into the other door

-- System made to suit full height timber storage cabinets

-- Lock housing measures 75mm x 30mm

-- 18mm diameter cylinder with a 22mm projection

-- Locking bolt has a projection of 8mm and is 16mm wide

-- All lock housings supplied with a bezel as standard

-- 2 x 1000mm long and  6mm diameter rods
